Specifications
Technical Specifications
| Property | KDC 340 | KDC 341W | Unit |
|---|---|---|---|
| Working Width | 3,50 | 3,50 | m |
| Transport width | 3,50 | 3,50 | m |
| Swath width | 2,20 - 2,50 | 1,60 - 2,10 | m |
| Necessary hydraulic couplers | 1 x single acting 1 x double acting | 1 x single acting 1 x double acting | — |
| Working capacity | 9.52 | 9.52 | fad/h |
| Number of discs | 8 | 8 | pcs. |
| Number of knives | 16 | 16 | pcs |
| Tires (with inner tubes) | 340 / 55 / 16 | 400 / 50 / 15 | pcs. |
| RPM | 540 / 1 000 | 540 / 1 000 | RPM |
| 3-point hitch cat. | II | II | II |
| Power demand | from 90 | from 110 | HP |
| Weight | 1 800 | 2 320 | kg |
