Specifications
Technical Specifications
| Property | Drum Mower 135 cm | Drum Mower 165 cm | Drum Mower 195 cm |
|---|---|---|---|
| Country of origin | Turkey | Turkey | Turkey |
| Length | 760 mm | 1.170 mm | 3200 mm |
| Width | 2600 mm | 2.850 mm | 900 mm |
| Height | 1000 mm | 1.310 mm | 900 mm |
| Weight | 360 Kg | 400 Kg | 500 Kg |
| Mowing Width | 1350 mm | 1610 mm | 1950 mm |
| Mowing Height Average | 70 mm | 70 mm | 70 mm |
| Working Capacity | 1.5 fed/hr | 2 fed/hr | 2.25 fed/hr |
| Number of Drums | 2 pieces | 2 pieces | 2 pieces |
| Number of Blades | 6 pieces | 6 pieces | 8 pieces |
| Tractor Power | 40 HP | 40 HP | 50 HP |
| PTO Tail Shaft Speed | 540 rpm | 540 rpm | 540 rpm |
| Working Speed | 8-10 Km / hr | 8-10 Km / hr | 8-10 Km / hr |
| V Belt Dimensions | - | 17*2850 mm | - |
| Blade Length | - | 106 mm | - |
| Blade Width | - | 46.5 mm | - |
| Blade Thickness | - | 3 mm | - |
